Audiofrog

subwoofers

Two types of subwoofers, one labeled GB 10 10 inches and the other GB 12 12 inches. Each type has a front view and a rear view, showing the speaker cones and the connection terminals.

GB Series subwoofers are designed for high-power handling and optimized to provide superior low-frequency extension from a wide range of sealed and vented enclosures.  A copper inductance-reducing pole piece cap also reduces distortion and extends the range of flat response well into the midbass.

Specifications:

  • Nominal Impedance: 1 Ω or 4 Ω (Model GB10D2 or GB12D2)

  • Nominal Impedance: 2 Ω or 8 Ω (Model GB10D4 or GB12D4)

  • RMS Power Handling: 500 W

  • Peak Power Handling: 1500 W

  • Frequency Response (-3 dB): 24 Hz – 200 kHz

  • Sensitivity (2.83 V/1 M): 93 dB (1 Ω configuration)

  • Recommended Amplifier RMS Power Range: 100 W – 1000 W

    Click here for Install Manual
